MV0000151791
S002VNG0750IE3D063M04
Helical worm geared motor
S002VNG0750IE3D063M04
Weight 15 kg
Frequency range 0 Hz
Nominal current 0,55 A
Ratio 74,70
Exact math. ratio 747/10
Motor torque 1,21 Nm
Output torque 70 Nm
Motor speed 1.415 1/min
Output speed 19 1/min
Motor power 0,18 kW
Service factor 1,0
Shaft design Solid shaft with key
Shaft dimension Ø20x40 NG w. key *96215
Position shaft / pinion Side 3
Housing design Foot + pitch circle diameter
Mounting position EL6
Lubrication Mobilgear 600 XP 220 *
CLP ISO VG 220
Efficiency class IE3
Pole number 4-pole
Line power 0.18kW
Option design Standard *
Voltage type Voltage from wide range +-5%
Frequency 50Hz
Voltage 220-240/380-420V
Protection class IP56
Thermal class 155 (F)
Brake Integrated brake
Cooling type Self-ventilated
Operating mode S1 operation
Terminal box position 0°
Cable entry Right
Brake connection type AC connection terminal board
Brake rectifier Powerbox rectifier
Brake voltage AC 190-277V PB DC115V/127V
Braking torque Spring-loaded brake 2.5Nm
