In modern industrial plants such as cement, steel, power, and chemical processing, baghouse (bag filter) systems play a critical role in controlling particulate emissions.

However, even high-efficiency bag filters can develop:

• Filter bag leaks
• Broken bags
• Improper cleaning cycles

👉 These issues lead to increased dust concentration downstream, causing:

• Environmental non-compliance
• Product loss
• Equipment damage

To address this, industries rely on advanced solutions from Auburn FilterSense, a global leader in continuous particulate monitoring and baghouse optimization.

2. Application: Measuring Dust Concentration After Bag Filters

Why measure dust after baghouse?

Post-bag filter monitoring is essential for:

• Emission compliance (EPA, MACT, NESHAP)
• Early bag leak detection
• Process optimization & predictive maintenance
• Reducing downtime and maintenance cost

👉 Continuous particulate monitoring enables real-time visibility of dust levels in:

• Stack emissions
• Ducts and pipelines
• Clean air side of baghouses

3. Technology Overview – DynaCHARGE™ Principle

Auburn FilterSense systems, including PM-1 PRO, use charge induction technology (DynaCHARGE™):

Working Principle

• Dust particles carry a natural electrostatic charge
• As particles pass near the probe, a small electrical signal (pA level) is induced
• The system converts this signal into dust concentration trends

👉 Advantages:

• Immune to temperature, moisture, and velocity variations
• No optical contamination issues
• Extremely sensitive to low dust levels

This makes it ideal for bag leak detection and low concentration measurement (<1–5 mg/m³)

4. Deep Technical Analysis – PM-1 PRO

Product Overview

The PM-1 PRO is a high-performance single-point particulate monitor, designed for:

• Baghouse leak detection
• Continuous emissions monitoring
• Industrial process optimization

It is recognized as a benchmark device for reliability and accuracy in harsh industrial environments

Key Technical Features

1. Ultra-High Sensitivity

• Resolution: ~0.1 pA (high precision signal detection)
• Detects dust levels as low as ~1 mg/m³

👉 Enables early detection of filter failure before major emissions occur.

2. Extreme Process Capability

• Temperature: up to 898°C
• Pressure: up to 6.9 bar

👉 Suitable for:

• Steel plants
• Cement kilns
• Incinerators

3. EPA-Compliant Performance

• Built-in self-test diagnostics (zero, span, linearity)
• Meets EPA performance requirements

👉 Ensures regulatory compliance and audit readiness

4. Advanced Diagnostics & Data Logging

• Device health diagnostics (NAMUR NE107)
• Event logging & trend analysis
• Real-time monitoring

👉 Supports predictive maintenance and remote troubleshooting.

5. Flexible Integration

• 4–20 mA output
• HART communication
• Bluetooth connectivity

👉 Easily integrates with:

• PLC / DCS systems
• SCADA platforms

5. Key Benefits of PM-1 PRO in Baghouse Applications

✔ Early detection of broken filter bags
✔ Reduced emissions and environmental risk
✔ Lower maintenance costs
✔ Improved process efficiency
✔ Real-time actionable data

6. Comparison of Auburn FilterSense PM Series

👉 PM-1 PRO stands out as:

• The best single-point solution
• Ideal for high temperature & critical applications

LTD đang là Đại lý tư vấn - phân phối - lắp đặt - kỹ thuật chuyên sâu thiết bị hãng Auburn tại Việt Nam

Dịch vụ cung cấp

• Tư vấn lựa chọn giải pháp đo bụi
• Lắp đặt & tích hợp hệ thống
• Sửa chữa – bảo trì – hiệu chuẩn
• Hỗ trợ kỹ thuật tại nhà máy

👉 LTD giúp khách hàng:

• Đạt chuẩn môi trường
• Giảm chi phí vận hành
• Tối ưu hệ thống baghouse

Liên hệ với chúng tôi ngay để được tư vấn và hỗ trợ giá tốt nhất:

Mr. Tri - 0912 300 549

- sale02@ltdautomation.com.vn
