Bộ mã hoá vòng quay FG 40 Ex.

• Particularly robust incremental optical encoder with a pressure-resistant housing made of seawater-resistant aluminium
• Ex-proof according to ATEX / IECEx: gas (zones 1 and 2), dust (zones 21 and 22)
• Solid shafts up to Ø 14 mm (flange mounting)
• Up to 250,000 pulses HTL / TTL, up to 2,500 sine periods
• Degree of protection IP66, ambient temperature range from -40 to +60 ºC
• Second signal output possible

Supply voltage: 12-30 VDC

Signal amplitude

• HTL or TTL
• Sin/Cos

Number of pulses

• Standard pulse rates for HTL, TTL und Sin/Cos: 500, 600, 1000, 1024, 1200, 1300, 2500
• Interpolation factors (for HTL/TTL pulses only): 1, 2, 4, 8, 10, 20, 40, 50, 100

Output signals: 0°, 90°, N, status and inverted signals

Maximum Speed / Frequency" Solid shaft: up to 6000 rpm / max. 200 kHz

Electrical connection: Terminal strip in a terminal box

Type of construction: Solid shaft (B5): Ø 11 mm, Ø 14 mm with feather key

Ambient temperature range

T5: -40 … +60 °C
T6: -40 … +55 °C

Degree of protection: IP66
