Bộ mã hoá vòng quay FGH 41 SIL 3.

• Particularly robust incremental encoders with a housing made of seawater-proof aluminium, suitable for use in wet areas of rolling mills
• Certified for safety applications up to SIL 3 / PL e
• Hollow shafts up to Ø 20 mm, solid shafts up to Ø 14 mm (flange or foot mounting)
• Up to 4,096 ppr HTL / TTL, up to 4,096 sine periods
• Degree of protection up to IP67, temperature range from -40 to +85 ºC
• Safety-certified solid or hollow shaft attachment possible

Supply voltage: 12-30 VDC

Signal amplitude

• HTL or TTL
• Sin/Cos

Number of pulses: 1024, 2048, 4096

Output signals

0°, 90° and inverted signals,Reference pulse (N) without SIL / PL, with inverted signal

Maximum Speed / Frequency

• Solid shaft: up to 4000 rpm / HTL and TTL: 100 kHz; Sin/Cos: 500 kHz
• Hollow shaft: up to 3000 rpm / HTL and TTL: 100 kHz; Sin/Cos: 500 kHz

Electrical connection

• Terminal strip in a terminal box
• Fixed cable
• 12-pole round connector M23

Type of construction

• Solid shaft (B5 / B35): Ø 11 mm, Ø 14 mm
• Hollow shaft: Ø 20 mm with keyway (for shafts up to max. length: 48 mm)

Device temperature range: -40 °C to +85 °C

Degree of protection up to IP66 / IP67

Shock resistance up to 100 g

Vibration resistance up to 10 g
