MV0000138982
K302SGD0200LM503U
MV0000138982
Helical bevel geared motor
K302SGD0200LM503U
Weight 33 kg
Stall current 5.95 A
Nominal current 5.62 A
Ratio 20.28
Exact math. ratio 3569/176
Motor torque 9.48 Nm
Stall torque 198 Nm
Output torque 186 Nm
Max. input speed cycle 6,000 rpm
Motor speed 3,000 rpm
Output speed 148 rpm
Motor power 2.97 kW
Backlash 10 arcmin
Service factor 1.5
Shaft design Hollow shaft with shrink ring
Shaft dimension Ø35/35 *99214
Position shaft / pinion Shrink ring side 4
Cover Side 4
Housing design PCD + torque arm bracket
Fastening torque arm Side 1 eye side 3
Mounting position EL2
Lubrication Mobilgear 600 XP 220 *
CLP ISO VG 220
Type designation motor LM503USATO135
Cooling type Convection cooling IC
Drive controller manufacturer STOBER
DC link voltage 540V DC link v./400VAC *
Drive controller type / conn. SI6 sensorless
Connection plan 443017
Nominal speed nN 3000rpm 540V (KEM=135)
Connector type Angle rotatable
Mating connector W/o mating connector
Power connection Plug connector 8pin con.23
Pos. of the plug connectors 0°
Thermal winding protection PTC in power connection
Surrounding temperature -15°C to +40°C
Thermal class (VDE 0530) 155 F
Protection class (EN 60529) IP56 (EN 60529)
Option design UR / CSA Recognized Components
Operating mode servo motors S1 Operating
