KOSO 501G Control Valve – Boiler Feedwater Control Valve ANSI 300

KOSO 501G – 5227SLADN is a cage-guided control valve configuration designed for industrial process control, including boiler feedwater systems where stable flow regulation, pressure control and continuous operation are required. The supplied configurations use ANSI Class 300, A216-WCB carbon-steel bodies, with nominal sizes from 50A to 125A.

The 501G series is designed with a pressure-balanced trim and is intended for high-Cv and dynamically stable operation in heavy-duty services. KOSO states that balancing the fluid pressure acting on the plug helps achieve stable control with lower operating force, making the series suitable for applications involving high pressure drops.

KOSO 501G Applications

In boiler feedwater systems, the control valve regulates water flow entering the boiler according to operating demand. Accurate control helps coordinate feedwater flow, boiler load and process pressure, while supporting stable operation of pumps, economizers and related equipment.

The KOSO 501G can also be applied to:

• Boiler and steam-generation systems
• Thermal power plants
• Steel and cement plants
• Chemical and petrochemical processes
• Industrial water and cooling-water systems
• High-pressure liquid and gas control applications

Supplied KOSO 501G Configurations

Note: The above configurations are based on the supplied specifications. The listed package does not include the pneumatic actuator/controller.

KOSO Technology – Stable Control for Heavy-Duty Service

The 501G Cage Guided Control Valve is manufactured with a pressure-balanced cage-guided construction. According to KOSO, the series covers body sizes from 1 to 18 inches, pressure ratings from ANSI Class 150 to 2500, and fluid temperatures from approximately -196°C to +538°C, depending on material and configuration. Rangeability is specified up to 50:1.

The design supports different flow characteristics and seat-leakage classes, while available actuator combinations include pneumatic diaphragm, pneumatic cylinder, electronic and microprocessor actuators.

Comparison of KOSO Control Valve Series

The 550G uses multi-hole cages to address low-noise and anti-cavitation requirements, while KOSO recommends its VeCTor technology for severe fluid conditions beyond the standard cage-guided range.

LTĐ – Authorized Distributor in Vietnam

LTĐ is an authorized distributor in Vietnam, providing KOSO control valves and industrial automation solutions.

We provide consulting, design, installation, commissioning, calibration, warranty and fast repair services, supporting customers in selecting the appropriate valve based on size, pressure class, Cv, process medium, temperature, pressure drop and control requirements.
