Transformer Temperature Control TR42CMW TR42CMB TR42ADW TR42ADB ORION VIỆT NAM
LTD Automation is proud to be a reputable distributor of ORION TR42 products in Vietnam
==> Why choose to buy ORION TR42 at LTD Automation:
- Prestige creates the brand
- 100% genuine products
- Comprehensive after-sales policy support
- Products are warranted for at least 12 months.
Contact for advice:
- 0912 300 549
- sale02@ltdautomation.com.vn
The TR42 from Orion Italia is a dedicated temperature relay/controller for three-phase dry or cast resin transformers (cast-resin / dry-type). The device allows monitoring the winding and core temperature of the transformer via 3 or 4 PT100 sensors, and can control the cooling fan, alarm or trip when the temperature exceeds the threshold. It is a professional solution for transformer temperature protection (ANSI 49 function) and is easily integrated into SCADA systems or monitoring systems via RS-485 Modbus.
Temperature monitoring and protection of dry-type transformers or cast resin transformers in factories, power stations, industrial processes.
Control cooling fan, ventilation system for transformer when temperature is high to increase life and load capacity.
Integration into control systems, SCADA or HMI thanks to RS-485/Modbus communication and (in some versions) 4-20mA signal output.
Used in industrial environments requiring high durability, stable operation, protection against overheating, fault sensors and fault devices.
| Criteria | Describe |
|---|---|
| Number of sensor channels | Supports 3 or 4 3-wire PT100 sensor inputs, suitable for measuring transformer coils and cores. |
| Thresholds and control programs | Allows programming of alarm (L1), interrupt (L2) and FAN control levels – flexible according to the application. |
| Communication & Signaling | There is a version that supports RS-485 Modbus and a version that also has a 4-20 mA signal for PLC/SCADA connection. |
| Measuring range & accuracy | Temperature measurement range is about –10 to +240 °C, accuracy ~ ±1% FS ±1 digit. |
| Integrated protection | Has weekly fan start function to protect bearings, PT100 sensor disconnection warning, device warning. |
| Industry standards | Designed for 96x96 mm panel mounting, IP54 front protection, RS-485 communication isolation up to ~1500 V, EMC/CEI/VDE compliant. |
| Flexible power supply | Supports 24 Vdc or 85-264 Vac (or 115-300 Vdc) power supply depending on version, suitable for a variety of applications. |
| Product line | Key Specifications & Highlights |
|---|---|
| TR42 (Standard) | Basic temperature relay/controller: 4 PT100, RS-485 Modbus, fan control, sensor disconnection warning. |
| TR42AD (4-20 mA & Modbus) | Similar to TR42 but adds 4-20 mA output signal for PLC/DCS connection, suitable when analog communication is required. |
| TR42CM (Modbus only) | Version with only RS-485 Modbus communication, no 4-20 mA signal — economical choice when only digital transmission is required over the network. |
