OFFICINE's W3 and W5 thermocouples are specialized thermocouples for measuring ultra-high temperatures , designed to operate reliably in harsh environments where conventional thermocouples cannot. Using a Tungsten (W) – Rhenium (Re) alloy , they can withstand temperatures up to 2310°C , meeting the stringent requirements of heavy industry and scientific research.

With years of experience in the field of high-temperature measurement equipment, OFFICINE provides accurate, durable, and reliable measurement solutions for industrial and laboratory furnace systems.

Uses of W3 – W5 Office Thermocouples

W3 and W5 OFFICINE thermocouples are primarily used for measuring, monitoring, and controlling temperatures in very high ranges , where K, S, or B type sensors are no longer suitable. Thanks to their special material properties, these products offer:

• Stable measurement capability over a long period of time.

• High accuracy at extreme temperatures

• Capable of operating effectively in inert gas or hydrogen environments .

Important note: Tungsten-Rhenium thermocouples should not be used in oxidizing environments , as oxygen will rapidly degrade the sensor's lifespan and stability.

Practical applications

W3-W5 OFFICINE thermocouples are widely used in many specialized fields such as:

• Vacuum furnace, inert gas furnace, hydrogen furnace

• Metallurgy , special alloying

• Manufacture of technical ceramics and refractory materials.

• Semiconductor industry , new materials

• Ultra-high temperature research laboratory

Thanks to its high durability and reliability, the product is particularly suitable for systems operating continuously under harsh conditions.

Basic technical specifications

• Sensor type : Tungsten-Rhenium thermocouple

• Manufacturer : OFFICINE

• Model : W3, W5

• Temperature measurement range : 0 – 2310°C

• Electrode composition : Tungsten doped with Rhenium

• Working environment : Inert gas, hydrogen

• Not suitable : Oxidizing environment

Comparison table of OFFICINE W3 and W5 thermocouple models
